BG Ultra-Guard® Full Synthetic Gear Lubricant
BG Ultra-Guard® Full Synthetic Gear Lubricant
PN 750PN 75032 PN 75064 PN 75096 |
BG Ultra-Guard® Full Synthetic Gear Lubricant is full synthetic API GL-5 rated gear lubricant blended to SAE 75W-90 viscosity. BG Ultra-Guard provides the ultimate protection for driveline components. It is formulated for maintaining system cleanliness, increased thermal stability, improved seal performance, quieter operation, and unsurpassed protection against wear, pitting, and corrosion.
SPECIFICATIONS
| Test | ASTM Test Method | Typical Test Results |
| Specific Gravity @ 15.6°C (60°F) | D1298 | 0.861 |
| API Gravity @ 15.6°C (60°F) | D287 | 32.8 |
| Density, U.S. lbs./gal. (kg/m³) @ 15.6°C (60°F) | D1250 | 7.178 (860.1) |
| Flash Point, COC | D92 | 198°C (388°F) |
| Viscosity, cSt @ 40°C (104°F) | D445 | 99.11 |
| Viscosity, cSt @ 100°C (212°F) | D445 | 14.53 |
| Viscosity Index | D2270 | 152 |
| Viscosity, cP @ –40°C (–40°F) | D2983 | 107,200 |
| Pour Point | D97 | –41°C (–42°F) |
| Color | D1500 | 2.0 |
| Color | Visual | Yellow |
| Copper Corrosion Test | D130 | 1b |
USAGE
Follow equipment manufacturer’s service recommendations. Keep the gearbox full. Excellent on-road, off-road and marine lubricant. For limited slip applications, BG Universal MGC®, PN 328, must be added at a 10% treat ratio.
FOR PROFESSIONAL USE.
BG Products, Inc., accepts no liability for excessive use or misuse of this product.
